Technical Overview
Installation type
Built-in
Width
90 cm
Cooktop-based rangehood control
No
Sound pressure recirculated air level 2
41 dB(A) re 1 pW
PerfectAir sensor
No
Operating Mode
Exhaust / Recirculation (Accessory available separately)
Max. air extraction
408 m³/h
Boost position air extraction
758 m³/h
Key Features
Specifications
Width
90 cm
Colour
Silver metallic
Installation type
Built-in
Operating Mode
Exhaust / Recirculation (Accessory available separately)
Total power of the motors
140 W
Type of control setting and signalling devices
Button
Number of power settings
3-stages + intensive setting
Max. air extraction
408 m³/h
Boost position air extraction
758 m³/h
Sound power at max. speed (2010/30/EC)
54 dB
Sound power boost (2010/30/EC)
69 dB
Max. air recirculation
358 m³/h
Boost position output recirculating
496 m³/h
Sound power at max. speed (recirculation)
60 dB
Sound power boost (recirculation)
67 dB
Grease filter material
Washable aluminium
Energy efficiency rating
A
Total annual energy consumption
38.5 kWh/year
Included user manuals
[EN]
Height of the appliance
426 mm
Width of the appliance
898 mm
Depth of the product
290 mm
Dimensions of the packed product (HxWxD)
400x940x480 mm
Minimum distance above an electric cooktop (EU)
430 mm
Minimum distance above a gas cooktop
650 mm
Diameter of air outlet
150 / 120 mm
No-return airflow flap
No
Length electrical supply cord
175 cm
Net weight
12.5 kg
Handle bar
enclosed
Appliance height exhaust air max
426 mm
Appliance height exhaust air min
426 mm
Appliance height recirculating max
426 mm
Appliance height recirculating min
426 mm
Maximum width for installation
524 mm
Minimum width for installation
524 mm
Depth for installation
290 mm
1 / 0
PerfectAir sensor
No
SilentPowerDrive motor - efficient and extra silent
Yes
Extremely silent appliances
Yes
Clean filter reminder
No
Boost mode
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
LED
Number of lights
2
Total power of the lamps
6 W
Total luminance
615 lux
Color temperature
Neutral (3.500 K)
Illumination type softlight
No
Light colour customisable by Home Connect
No
Ambient light
No
Wi-Fi Enabled (Home Connect)
No
Cooktop-based rangehood control
No
Smart Hood Automatic
No
